TECHNICAL SPECIFICATIONS

PRODUCT SPECIFICATIONS

• Agency Approval: UL 1363, 1449
• LED Indicators 4
• Grounding Requirements Uses Electrical AC Ground
• Width / Height / Depth / Weight: 4.25" / 12.75" / 1.5" / 2.4lbs
• Product Warranty 5 years
• Connected Equipment Warranty Up to $50,000

AC SURGE PROTECTION:

• SurgeGate Plus Circuitry Yes
• Thermal Fusing Yes
• Catastrophic Surge Circuit Yes
• Over/Undervoltage Voltage Protection Yes
• Overvoltage Voltage Shutoff 144V ± 8V
• Undervoltage Voltage Shutoff 87V ± 8V
• single Pulse Energy Dissipation 1850 Joules
• Peak Impulse Current 52,000A
• EMI/RFI Noise Filtration 50db (99.7&percent;)
• Line voltage 120V (50/60Hz)
• Initial Clamping Level 200V Peak, 141 RMS
• UL 1449 Suppression Rating L-N 400V, L-G 400V, N-G 400V
• Pretections Modes L-N, L-G, N-G
• Maximum Current Rating 15A (1800W)
• Reponse Time 1-5 Nanoseconds
• Plug Configuration Right Angle
• Number of Outlets / Switched Outlets / Cord Length 8 / 8 / 8'
• 2 Grounding and Line Faults: Ground OK=Green Light ON; Line Fault=Red Light ON;  Power/Protection OK=Green Light ON; Unsafe Voltage=Red Light ON
